Platform : Dual CPU Rack Server
Processor Type : Intel Xeon Eight Core
#1 Processor Onboard : Intel® Xeon® Processor E5-2620v3 (15M Cache, 2.40 GHz)
#2 Processor Onboard : Intel® Xeon® Processor E5-2630v3 (20M Cache, 2.40 GHz)
Chipset : Intel C612
Standard Memory : 8 x 16GB DDR4 PC-17000 2133Mhz RDIMM
Max. Memory : Up to 24 DIMM sockets (12 DIMMs per processor)
Video Type : Integrated Matrox G200eR2 16MB
#1 Controller : SR M5210
#1 Hard Drive : 2 x 2TB 7.2K 6Gbps NL SATA 3.5
#1 Optical Drive : DVD±RW
Standard Bays : 12 x 3.5" hot-swap SATA HDDs
Interface Provided : Front : 2 x USB 2.0, 1 x USB 3.0, 1 x DB-15 video ; Rear : 2 x USB 3.0, 2 x USB 2.0, 1 x DB-15 video, 1 x RJ-45 Systems Management, 4 x RJ-45 GbE network ports
Slot Provided : Up to 8 PCI Express Adapter Slots
Networking Integrated Four Gigabit Ethernet 1000BASE-T Ports
System Fans / Coolers : Up to six redundant hot-swap fans
Chassis Form Factor : 2U Rackmount Chassis
Power Supply Type : 2 x 550W
System Management : UEFI, Integrated Management Module II (IMM2.1) based on Renesas SH7758, Predictive Failure Analysis, light path diagnostics, Automatic Server Restart, ToolsCenter, IBM Systems Director and Active Energy Manager
O/S Provided : Not Available
Dimensions (W x H x D) : 86.5mm x 445.6mm x 800mm (H x W x D)
Weight : Min : 19Kg, Max : 34Kg
Standard Warranty : 3-Years Warranty by IBM Indonesia (3-Years Next Bussiness Day Parts Replacement, 3-Years Labor, 3-Years Onsite Support)
